3M Touch Systems 41-81365-227 Touchscreen
Part #: 41-81365-227 | SKU: 3M 24273

We envisioned a touch monitor that would set a new standard of excellence creating a monitor form factor that is a breakthrough in display design. Meeting this goal required fresh thinking novel methods and ultimately a totally new touch monitor. The MicroTouch M150 Touch Monitor is the culmination of this innovative new approach. ----Touch monitor users know standard desktop monitors and touch monitors are worlds apart. Flat panel monitors are slim sleek lightweight and typically have a small footprint. All of this can translate into a monitor that is unstable to the touch. We designed the M150 monitor to offer all of the benefits that LCD technology affords yet remain remarkably stable to the touch. The M150 offers a patent-pending feature set combining stability adjustability aesthetics and mounting flexibility in a compact package.

3M Touch Systems 41-81365-227 Touchscreen

Part Details: M150 FPD Touch Monitor (15 Inch Desktop LCD, Serial Interface, Resistive and Multimedia) - Color: Beige

Need a different version of the 3M Touch Systems M150 FPD Touchscreen? View all 12 configurations

Additional Information

Manufacturer AIDC	3M Touch Systems
Model Name	M150 FPD

3M Touch Systems M150 FPD Specs (pdf)

Technical Information

Touch Screen Type: 5 Wire Resistive
Screen Size: 15" - Active Matrix TFT LCD
Dot Pitch: 0.297mm
Monitor Response Time: 16ms Typical
Mountable: VESA
Front Panel Controls: Menu Adjust Select Power
OSD Controls: Brightness Contrast Horizontal Position Vertical Position Clock Phase Auto Phase Color

General Information

Manufacturer: 3M
Product Line: MicroTouch
Product Name: MicroTouch M150 Touch Screen Monitor

Physical Characteristics

Color: Beige
Dimensions: 398.3mm (16") x 408mm (16") x 258.7mm (10") - Depth Includes Base
Weight: 7.4 kg (16.31 lb) - Net

Interfaces/Ports

Interfaces:
- 15-pin - HD DB-15
- Serial
- Audio Input
- Audio Output

Environmental Conditions

Temperature:
- 0Â°C (32Â°F) to 50Â°C (122Â°F) Operating
- -20Â°C (-4Â°F) to 60Â°C (140Â°F) Storage
Humidity: 85% Operating Non-condensing

Display & Graphics

Maximum Resolution: 1024 x 768
Brightness: 250 cd/m2
Ratio: 350:1 - Contrast Ratio

Power Description

Input Voltage: 12 V DC
Power Consumption: 28W - Normal Operation
Power Management: VESA DPMS

Agency Approvals

Agency Approvals: RoHS Compliant FCC Class B CE UL/cUL C-Tick VCCI CCC

Other

Additional Information: Color: 16 Millions Colors Viewing Angle: Horizontal: 150Â° Vertical: 135Â°

Warranty

Manufacturer Warranty: 3 Year(s) Limited

Extended Details
