APC SMX3000HVT Accessory
Part #: SMX3000HVT | SKU: APC258556

Products and parts from APC.

APC SMX3000HVT Accessory

Part Details: APC by Schneider Electric Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V - 4U Tower, Rack-mountable - 3 Hour Recharge - 6.30 Minute Stand-by - 208 V AC Input - 4 x IEC 60320 C13, 2 x IEC 60320 C19, 2 x NEMA L6-20R

Need a different version of the APC Parts Accessory? View all 465 configurations

MSRP: $3,765.00 Price: $2,665.46

In Stock

Additional Information

Manufacturer	APC
Model Name	Parts

Technical Information

Receptacles:
- 4 x IEC 60320 C13
- 2 x IEC 60320 C19
- 2 x IEC Jumper
- 2 x NEMA L6-20R
Plug/Connector Type:
- IEC 60320 C20
- SCHUKO CEE 7 EU1-16P
- British BS1363A
Protection Type: Surge
Cord Length: 6 ft
Emergency Power OFF: Yes

General Information

Product Type: Line-interactive UPS
Product Series: X
Brand Name: APC
Manufacturer: American Power Conversion Corp
Product Name: Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V
Product Line: Smart-UPS

Physical Characteristics

Height: 17"
Width: 7"
Depth: 19"
Rack Height: 4U
Form Factor:
- Tower
- Rack-mountable
Weight (Approximate): 85 lb
Color: Black

Interfaces/Ports

USB: Yes
Serial Port: Yes
Total Number of Expansion Slots: 1

Other

Package Contents:
- Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V
- CD with Software
- Documentation CD
- Rack Mounting Brackets
- Smart UPS Signalling RS-232 Cable
- USB Cable
- User Manual
- Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V
- CD with Software
- Documentation CD
- Rack Mounting Brackets
- Smart UPS Signalling RS-232 Cable
- USB Cable
- User Manual
Green Compliant: Yes
Green Compliance Certificate/Authority:
- REACH
- RoHS
Certifications & Standards:
- C-tick
- CE
- CSA
- EN 50091-1
- EN 50091-2
- EN 60950
- FCC Part 15 Class A
- GOST
- IRAM
- UL 1778
- VDE
- UL 1449

Power Description

Load Capacity (VA): 3000 VA
Load Capacity (Watt): 2700 W
Input Voltage: 208 V AC
Output Voltage: 230 V AC
Circuit Breaker: Yes
Surge Energy Rating: 645 J
Waveform Type: Sine Wave

Battery Information

Maximum Battery Recharge Time: 3 Hour
Number of Batteries: 1
Backup/Run Time (Half Load): 15.70 Minute
Backup/Run Time (Full Load): 6.30 Minute
Battery Characteristics: Maintenance-free, Sealed, Spill-proof
Battery Chemistry: Lead Acid
Hot Swappable: Yes

Management

Alarm:
- Low Battery
- On Battery
- Configurable Delay

Environmental Conditions

Temperature: 113°F (45°C)
Thermal Dissipation: 184 BTU/h
Sound Emission: 55 dB(A)

Controls/Indicators

Status Indicators: LED status display with On Line : On Battery : Replace Battery and Overload indicators

Warranty

Limited Warranty: 3 Year
