APC SUA3000RM2U UPS
Part #: SUA3000RM2U | SKU: APC24312

APC Rack Automatic Transfer Switch , Input: 208V , Input Connections: NEMA L6-20P , Cord Length: 6 feet ( 1.83 meters ) , Output: 208V , Output Connections: NEMA L6-20R

APC SUA3000RM2U UPS

Part Details: Smart-UPS 3000VA USB & Serial RM 2U 120V

Need a different version of the APC Smart-UPS Series Accessory? View all 33 configurations

Additional Information

Manufacturer	APC
Model Name	Smart-UPS Series

Technical Information

Receptacles:
- 6 x NEMA 5-15R
- 2 x NEMA 5-20R
Plug/Connector Type: NEMA L5-30P
Cord Length: 8 ft
Emergency Power OFF: Yes

General Information

Product Type: Line-interactive UPS
Brand Name: APC
Manufacturer: American Power Conversion Corp
Product Name: Smart-UPS 3000VA
Product Line: Smart-UPS

Physical Characteristics

Height: 3.5"
Width: 19"
Depth: 26"
Rack Height: 2U
Weight (Approximate): 96 lb
Color: Black

Interfaces/Ports

USB: Yes
Serial Port: Yes
Total Number of Expansion Slots: 1

Other

Package Contents:
- Smart UPS
- Software CD
- Rack Mounting Brackets
- Signalling RS-232 cable
- USB cable
- User Manual
- Smart UPS
- Software CD
- Rack Mounting Brackets
- Signalling RS-232 cable
- USB cable
- User Manual
Certifications & Standards:
- BSMI
- CSA
- UL 1449
- UL 1778
- FCC Part 15 Class A
Additional Information:
- Automatic Self Test
- Automatic Voltage Regulation (AVR)
- Lightning and Surge Protection
- Load Meter
- Network-grade line conditioning
- Wide input voltage range

Controls/Indicators

Status Indicators:
- On Line
- On Battery
- Replace Battery
- Overload
- Wiring Fault
- Status

Power Description

Load Capacity (VA): 3000 VA
Load Capacity (Watt): 2700 W
Input Voltage: 110 V AC
Output Voltage: 120 V AC
Surge Energy Rating: 480 J
Waveform Type: Sine Wave

Battery Information

Backup/Run Time (Half Load): 11.30 Minute
Backup/Run Time (Full Load): 3 Minute
Battery Characteristics: Spill-proof, Maintenance-free
Battery Chemistry: Sealed Lead Acid
Hot Swappable: Yes

Management

Network Management: SNMP Manageable
Battery Management: Intelligent Battery Management
Alarm:
- On Battery
- Low Battery

Environmental Conditions

Temperature: 113°F (45°C)
Thermal Dissipation: 400 BTU/h

Warranty

Limited Warranty: 2 Year

Extended Details
