Additional Information
| Manufacturer AIDC | APC |
|---|---|
| Model Name | Smart-UPS Series |
Technical Information
- Power Rating: 4.80 kVA
- Input Receptacles: NEMA L6-30P
- Output Receptacles:
- 8 x NEMA 5-20R Protected
- 1 x NEMA L14-30R Protected
- 2 x NEMA L6-20R Protected
- 1 x NEMA L6-30R Protected
General Information
- Product Type: Step Down Transformer
- Brand Name: APC
- Manufacturer: American Power Conversion Corp
- Product Name: 4.8K VA Isolated Step-Down Transformer
Physical Characteristics
- Height: 5.1"
- Width: 17"
- Depth: 26"
- Form Factor: 2U 19" Rack-mountable
- Weight (Approximate): 125 lb
- Color: Black
- Power Cord/Cable: 3 ft
Other
- Package Contents:
- 4.8K VA Isolated Step-Down Transformer
- Installation Guide
- Mounting hardware
- User Manual
- 4.8K VA Isolated Step-Down Transformer
- Installation Guide
- Mounting hardware
- User Manual
- Certifications & Standards:
- CSA
- UL Listed
- Compatibility:
- APC Symmetra Series
- Smart-UPS RT 208V Series
- Additional Information:
- Units per Pallet: 6
- Heavy Duty Design
Power Description
- Current:
- 30 A Input Current
- 30 A Output Current
- Input Voltage: 220 V AC
- Output Voltage:
- 120 V AC Nominal
- 208 V AC Nominal
- Input Voltage Range:
- 208 V AC Nominal
- 180 V AC to 264 V AC
- Frequency:
- 50 Hz
- 60 Hz
Environmental Conditions
- Altitude:
- 0 ft to 10000 ft Operating
- 0 ft to 50000 ft Storage
- Humidity:
- 0 to 95% Relative Humidity Operating
- 0 to 95% Relative Humidity Storage
- Temperature:
- 32°F (0°C) to 104°F (40°C) Operating
- -13°F (-25°C) to 149°F (65°C) Storage
Warranty
- Limited Warranty: 2 Year
- Parts Warranty/Labor: 2 Year
