APC SUVTP15KF4B4S UPS
Part #: SUVTP15KF4B4S | SKU: APC213302

APC Rack Automatic Transfer Switch , Input: 208V , Input Connections: NEMA L6-20P , Cord Length: 6 feet ( 1.83 meters ) , Output: 208V , Output Connections: NEMA L6-20R

APC SUVTP15KF4B4S UPS

Part Details: APC Smart-UPS VT 15kVA Tower UPS - 27 Minute Full Load - 15kVA - SNMP Manageable

Need a different version of the APC Smart-UPS Series Accessory? View all 33 configurations

MSRP: $18,645.00 Price: $12,775.45

Additional Information

Manufacturer AIDC	APC
Model Name	Smart-UPS Series

General Information

Product Type: Dual Conversion Online UPS
Product Series: VT
Brand Name: APC
Manufacturer: American Power Conversion Corp
Product Name: Smart-UPS VT 15kVA Tower UPS
Product Line: Smart-UPS

Technical Information

Receptacles:
- 1 x Hard Wire 5-wire 3PH + N + G
- 1 x Screw Terminal
Plug/Connector Type: Hard Wire 5-wire 3PH + N + G
Interfaces/Ports: DB-9 RS-232 Serial

Physical Characteristics

Height: 59"
Width: 20.6"
Depth: 32"
Form Factor: Tower
Weight (Approximate): 1318 lb

Interfaces/Ports

Modular Slots: SmartSlot
Interfaces/Ports: DB-9 RS-232 Serial

Other

Package Contents:
- Smart-UPS VT 15kVA Tower UPS
- Battery modules
- Bolt down brackets
- CD with software
- Installation guide
- Power modules
- Smart UPS signalling RS-232 cable
- Start up included
- User Manual
- Web/SNMP Management Card
- Smart-UPS VT 15kVA Tower UPS
- Battery modules
- Bolt down brackets
- CD with software
- Installation guide
- Power modules
- Smart UPS signalling RS-232 cable
- Start up included
- User Manual
- Web/SNMP Management Card

Power Description

Input Voltage Range:
- 208 V AC 3-phase Nominal
- 160 V AC to 240 V AC Mains Operation
Load Capacity: 15 kVA/12 kW
Input Voltage: 220 V AC
Output Voltage:
- 120 V AC Nominal
- 208 V AC Nominal
- 208 V AC 3-phase Nominal
- 208 V AC 3-phase Configurable
- 220 V AC 3-phase Configurable
Current: 40 A Maximum Input Current
Frequency:
- 57 to 63 Hz Output
- 40 to 70 Hz Input
Input Current: 40 A

Management

Network Management: SNMP Manageable Included
Bypass Switch:
- Internal
- Maintenance
- Static
- Automatic
- Manual
Emergency Power OFF: Yes
Overload Protection: 60A Input Breaker

Battery Information

Batteries: Valve-regulated Lead Acid (VRLA) User Replaceable Hot-swappable
Backup/Run Time:
- 0.45 Hour 12 kW Full Load
- 1.09 Hour 6 kW Half Load
Battery Recharge Time: 5 Hour Typical

Scalability

Modules: 4 x Battery Module

Warranty

Limited Warranty: 1 Year

Extended Details
