Additional Information
| Environment | Outdoor |
|---|---|
| Frequency | 2.4 - 2.5GHz |
| Manufacturer | HPE Aruba |
| Model Name | Antennas |
| Polarization | Vertical |
| Type | No |
Technical Information
- Antenna Gain: 3.3 dBi
- Directivity: Omni-directional
- Frequency Band Type:
- UHF
- SHF
- Frequency:
- 2.40 GHz to 2.50 GHz
- 4.90 GHz to 5.99 GHz
- Impedance: 50 Ohm
- Polarization: Linear Vertical
General Information
- Product Type: Antenna
- Brand Name: Aruba Networks
- Manufacturer: Aruba Networks, Inc
- Product Model: AP-ANT-90
- Product Name: AP-ANT-90 Omni-Directional Diversity Antenna
Physical Characteristics
- Height: 3.7"
- Width: 0.9"
- Depth: 6.2"
Interfaces/Ports
- Connector Type: N-Type
Other
- Application/Usage: Wireless Data Network
- Additional Information:
- VSWR: < 2.0:1
- Housing: Acrylic/PVC and Weatherproof
- FLY Cable Length: Dual 36 inch
- Beamwidth:
- Elevation:
- Lowband 2.400-2.500Ghz (57 to 61 degree)
- Highband 4.900Ghz (61 degree)
- Highband 5.150Ghz (59 degree)
- Highband 5.550Ghz (57 degree)
- Highband 5.900Ghz (55 degree)
- Azimuth:
- Omni-directional (360 degree)
