Avery-Dennison AD Dogbone M830 RFID Tag

The Avery Dennison AD Dogbone® M830 is a high-performance RFID inlay crafted to excel in demanding applications and environments. It operates within the UHF frequency spectrum of 860 - 960 MHz, employing Direct Chip Attach technology with the Impinj M830 chip. This sophisticated inlay is tailored for global supply chain, industrial, RTI, and sports timing applications, delivering superior performance on challenging-to-tag materials due to its strong resistance to the detuning effects of high dielectric substances.Key features of the AD Dogbone M830 include an antenna measuring 94 x 24 mm (3.70 x 0.95 in) and adherence to the ISO 18000-63 EPC class 1 Gen 2 international standard. It is outfitted with 128-bit EPC memory and a 96-bit unique factory-locked TID number, along with a 48-bit unique serial number encoded into the TID. This ensures enhanced readability and dependable performance in high-volume and rapid environments, facilitating global IoT implementations.The AD Dogbone M830 is offered in both wet inlay and label delivery formats, with a die-cut size of 97 x 27 mm (3.82 x 1.06 in), optimized for 100 mm (3.94 in) wide converted labels. The inlay substrate is composed of PET, with face sheet options of clear PET 12 or white PET 50, and a total thickness range of 118 µm to 173 µm. The standard pitch is 30 mm (1.18 in), with a web width of 100 mm (3.94 in) and a core size of 76 mm (3 in). Each reel comprises 5,000 units, with operational temperatures spanning from -40 °C to 85 °C (-40 °F to 185 °F).Produced to meet rigorous quality standards, the AD Dogbone M830 has earned extensive ARC certification for quality from the RFID Lab at Auburn University. It complies with RoHS EU Directive 2011/65/EC and Directive (EU) 2015/863, as well as REACH Regulation (EC) No. 1907/2006. Users are encouraged to thoroughly test the product in their specific applications to ensure it satisfies all requirements. For additional details and to reach Avery Dennison, visit rfid.averydennison.com/contact or call +1-678-617-2359.

Features and Benefits

• Dimensions: 94 x 24 mm / 3.70 x 0.95 in.
• Frequency Range: 860-960 MHz.
• Impinj M830 chip.
• Excellent performance on varied materials.
• Resistance to detuning effects from plastics.
• ARC certification.
• Available in wet inlay and label formats.
• Enhanced readability in high-volume environments.
• Clear PET 12 or White PET 50 Face Sheet.
