Custom America XM90 Credit Card Reader

SWIPE FUNCTION:
SWIPE METHOD F2F complies with ISO and JIS standard
SWIPE SPEED 5 - 60 inch / sec
INDICATOR BUZZER programmable
INDICATOR LED green = good read, red = bad

CARD STANDARD:
track 1 IATA, track 2 ABA, track 3 THRIFT, JIS-II, JIS x 6301 standard

CARD DENSITY:
track 1 - 79 characters (7 bit code), track 2 - 40 characters (5 bit code),track 3 - 107 characters (5 bit code), JIS-II - 79 characters (7 bit code)

RELIABILITY:
HEAD LIFE minimum 1,000,000 passes

PHYSICAL:
WEIGHT .13 lbs
DIMENSION (LxWxH) 3.8" x 1.2" x 1.27"
COLOR black
CABLE LENGTH 4.9 ft
POWER SUPPLY +5vDC + 10%
CURRENT CONSUMPTION <100mA
INTERFACE PS2 keyboard wedge, USB, RS232

ENVIRONMENTAL:
OPERATING TEMPERATURE 32 - 122?F
STORAGE TEMPERATURE -4 - 140?F
OPERATING HUMIDITY 20 - 90%

WHAT?S IN THE BOX:
magnetic stripe reader, cable / power supply, programming software, instructions

WARRANTY:
1 year parts
