Datalogic Gryphon I GD4100 Barcode Scanner

Datalogic Barcode Scanner and Mobile Handheld Computer

Datalogic Gryphon I GD4100 Barcode Scanner
Part #: GD4110-BKK20 | SKU: DAT72369

The Datalogic Gryphon I GD4100's stylish enclosures, reduced weight and physical dimensions together with a 1.8 m / 5.9 ft drop resistance and IP42 sealing rating produce a reliable, ergonomic solution with the combined excellence of ease of use and advanced reading capabilities.

Datalogic Gryphon I GD4100 Barcode Scanner

Part Details: Datalogic Gryphon GD4110 Handheld Barcode Scanner Kit - Cable Connectivity - 325 scan/s - 23.62" Scan Distance - 1D - LED - CCD - Linear - Serial - Black

Need a different version of the Datalogic Gryphon I GD4100 Barcode Scanner? View all 13 configurations

Additional Information

Connection	RS-232 Serial
Form Factor	Handheld
Manufacturer	Datalogic
Model Name	Gryphon I GD4100
Scanner Capability	1D
Scanner Type	Imager

Datalogic Gryphon I GD4100 Specs (pdf)

Decoding Capability

1D / Linear codes
- Autodiscriminates all standard 1D codes including GS1 DataBar linear codes
Stacked Codes
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional

Electrical

Current
- Operating (Typical)
  - GD4110
    225 mA @ 5 VDC
  - GD4130
    245 mA @ 5 VDC
- Standby/Idle (Typical)
  - 120 mA @ 5 VDC
Input Voltage
- GD4110
  4.5 - 14.0 VDC
- GD4130
  4.75 - 5.25 VDC

Environmental

Ambient Light
- 0 - 100,000 lux
Drop Resistance
- Withstands repeated drops from 1.8 m / 5.9 ft onto a concrete surface
ESD Protection (Air Discharge)
- 16 kV
Humidity (Non-Condensing)
- 0 - 90%
Particulate and Water Sealing
- IP42
Temperature
- Operating
  - 0 to 55 ?C / 32 to 131 ?F
- Storage/Transport
  - -20 to 70 ?C / -4 to 158 ?F

Interfaces

RS-232 / IBM 46XX / USB Multi-Interface
RS-232 / USB / Keyboard Wedge / Wand Multi-Interface

Physical Characteristics

Colors Available
- Black
- White
Dimensions
- 18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in
Weight
- 169.0 g / 6.0 oz

Reading Performance

Imager Sensor
- CCD Solid-State
Light Source
- Illumination
  - Dual LED Array 630 - 670 nm
Print Contrast Ratio (Minimum)
- 15%
Read Rate (Maximum)
- 325 reads/sec.
Reading Angle
- Pitch
  - 65?
- Roll (Tilt)
  - 35?
- Skew (Yaw)
  - 65?
Reading Indicators
- Beeper (Adjustable Tone and Volume)
- Datalogic 'Green Spot' Good Read Feedback
- Good Read LED
Resolution (Maximum)
- 0.076 mm / 3 mils

Reading Ranges - Typical Depth of Field

Minimum distance determined by symbol length and scan angle.
Printing resolution, contrast, and ambient light dependent.
5 mils
- 6.0 to 18.0 cm / 2.3 to 7.0 in
7.5 mils
- 3.5 to 30.0 cm / 1.4 to 11.7 in
10 mils
- 2.0 to 45.0 cm / 0.8 to 17.7 in
13 mils
- 3.0 to 60.0 cm / 1.2 to 23.4 in
20 mils
- 3.0 to 80.0 cm / 1.2 to 31.2 in

Safety & Regulatory

Agency Approvals
- The product meets necessary safety and regulatory approvals for its intended use.
- The Quick Reference Guide for this product can be referred to for a complete list of certifications.
Environmental Compliance
- Complies to China RoHS
- Complies to EU RoHS
LED Classification
- IEC 60825-1 Class 1 LED Product

Utilities

Datalogic Aladdin
- Datalogic Aladdin configuration program is available for download at no charge
OPOS / JavaPOS
- JavaPOS Utilities are available for download at no charge
- OPOS Utilities are available for download at no charge
Remote Host Download
- Lowers service costs and improves operations
  - GD4110

Warranty

5-Year Factory Warranty
