Datalogic QS65-4030000 Barcode Scanner
Part #: QS65-4030000 | SKU: DAT32042

The QuickScan QS6500 is Datalogic's newest general purpose handheld scanner, featuring the latest in linear imaging technology. For retail, office, healthcare and light industrial customers looking for a handheld scanner that has premium performance and durability at an affordable price, the QuickScan QS6500 offers the best price/performance in the market. The QS6500 provides many benefits including aggressive scanning performance, an ergonomic enclosure, excellent depth-of-field, snappy 1D and PDF bar code reading, bright targeting beam, and superior durability and reliability.

Datalogic QS65-4030000 Barcode Scanner

Part Details: QS6500 PDF Imager (RS232, 1D PLUS PDF with Multi-Interface Scan Only) - Color: Black

Need a different version of the Datalogic QS6500 Barcode Scanner? View all 18 configurations

Additional Information

Manufacturer	Datalogic
Model Name	QS6500
Scanner Capability	1D

Datalogic QS6500 Specs (pdf)

Technical Information

Form Factor: Handheld Scanner
Barcode Dimension: 1D
Resolution: 5 mil(s)
Symbologies Supported:
- UPC-A
- UPC-E
- EAN-8
- EAN-13
- JAN-8
- JAN-13
- RSS-14 Stacked
- RSS-14 Expanded
- RSS-14
- RSS-14 Limited
- ISBN / Bookland EAN
- Code 39 Full ASCII
- Pharmacode 39
- Code 128
- Code 93
- Interleaved 2 of 5
- Standard 2 of 5
- IATA
- Code 16K
- Code 11
- Codabar (NW7)
- UK Plessey
- MSI/PLESSEY
- RSS Composite
- UCC/EAN Composite Codes
- PDF 417
- Micro PDF
Scanner Type: Imager
Scan Rate: 450 scans/sec (max)
Interface Options:
- RS-232
- Keyboard Wedge
- IBM 46XX
- IBM USB
- USB
Interface Connectivity: Corded
Scan Pattern: Linear
Input Voltage Range: 4.5 to 14 V DC
Depth of Field:
- 2 - 5"@5mils
- 1 - 7"@7.5mils
- 0 - 12"@10mils
- 0 - 14"@13mils
- 24"@20mils
- 40"@40mils

General Information

Manufacturer:
- PSC Inc.
- Datalogic S.p.A
Product Line: QuickScan
Product Name: QuickScan QS6500 Barcode Scanner

Physical Characteristics

Dimensions: 6" (152.4mm) x 2.9" (73.66mm) x 3.9" (99.06mm)
Weight: 6.4 oz
Color: Black

Agency Approvals

Agency Approvals:
- EN60950
- CSA60950
- UL60950
- FCC-A
- EN 55022-B
- BSMI 13438
- AS/NZS 3548
- VCCI-B
- ICES-003

Environmental Conditions

Temperature:
- 0Â°C (32Â°F) to 50Â°C (122Â°F) Operating
- -40Â°C (-40Â°F) to 70Â°C (158Â°F) Storage
Humidity: 5 to 95% Non-condensing

Warranty

Manufacturer Warranty: 5 Year(s)

Extended Details
