Specifications Overview
| Print Method: |
Dye-Sublimation / Resin Thermal Transfer |
| Resolution: |
300 dpi (11.8 dots/mm) |
| Colors: |
Up to 16.7 million / 256 shades per pixel |
| Print Speed:** |
7 seconds per card (K)* |
|
12 seconds per card (KO)* |
|
27 seconds per card (YMCKO)* |
|
35 seconds per card (YMCKOK)* |
| Print Applications: |
Single- or dual-sided printing for text, logos, bar
codes, signatures and photos in
full-color |
| Input Hopper Card Capacity: |
100 cards (.030" / .762mm) |
| Output Hopper Card Capacity: |
Up to 30 cards (.030" / .762mm) |
| Print Area: |
CR-80 edge-to-edge (3.37"L x 2.11"W / 85.5mmL x 53.5mmW) |
|
CR-79 (3.3"L x 2.04"W / 83.8mmL x 51.8mmW) |
| Options: |
Magnetic Stripe Encoding Module - field-upgradeable |
|
Dual-sided Printing |
|
Printer Cleaning Kit |
*Indicates the ribbon type and the number of ribbon panels printed
where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black, O=Overlay
**Print speed indicates an approximate print speed and is measured
from the time a card feeds into the printer to the time it ejects
from the printer. Print speeds do not include encoding time or the
time needed for the PC to process the image. Process time is
dependent on the size of the file, the CPU, amount of RAM and the
amount of available resources at the time of the print.
