HID 601131-010 RFID Tag
Part #: 601131-010 | SKU: HID769809

Poly TagⓇ offers low and high-frequency disc-shaped RFID tags that are meticulously designed to perform under demanding outdoor conditions. Constructed with a sturdy polycarbonate shell, these tags boast shock resistance, waterproof capabilities, and can endure temperatures reaching 266°F (130°C). Available in low and high-frequency designs, they excel in asset tracking, logistics, and manufacturing settings. With ATEX/IECEX certification, the Poly Tag is suitable for explosive environments and can be personalized through laser engraving, making it an ideal choice for industries like mining and oil and gas.

Key Features:

• Durable housing - withstands shock, impact, and vibration; waterproof; resistant to chemical exposure
• ATEX/IECEX certified flame-resistant options for hazardous environments
• Heat tolerant – operational stability in extreme storage and processing conditions
• Versatile mounts - securely attaches to plastic or wood with screws
• Cost-effective - excellent size to performance ratios

Specifications:

• Base Model Number: 601131-010 Poly Tag®
• Operating Frequency: 125 kHz / 13.56 MHz
• Chip Type: Unique ICODE SLIX2
• Memory: 64 bit read-only / 2560 bit user memory
• Reading Distance: Dependent upon reader, environment, and application
• Dimensions: Ø 34 x 8 mm (01.34 x 0.31 in)
• Mounting Method: Screw-on
• Housing Material: PA6 - high impact - glass fiber reinforced
• Color: Black / Yellow
• Weight: 2.7 oz (7.8 g)
• Water Resistance: IP69K, IP68
• Flame Resistance: UL 94 V-0
• Warranty: 2 Years
