| Manufacturer | Mailing |
|---|---|
| Model Name | Handle With Care |
| Type | No |
General Information
Technical Information
- Receptacles:
- 2
- 2 x NEMA 5-15R
- Protection Type:
- Overvoltage
- Undervoltage
- Lightning
- Plug/Connector Type: Power NEMA 5-15
Physical Characteristics
- Height:
- 5.5"
- 2"
- Width:
- 3.5"
- 3.1"
- Depth:
- 2"
- 5.5"
- Weight (Approximate):
- 11.84 oz
- 9.28 oz
- Color: Black
Other
- Certifications & Standards:
- UL 1449
- UL 1449 (TVSS Rating 330V)
- cULus
- Compatibility:
- SOHO
- Alarms
- Printers
- Copiers
- Cameras
- TVs / VCRs
- Workstations
- Fax Machines
- Access Controls
- Telephone Systems
- Additional Information:
- Protection Circuitry:
- SurgeGate Plus Circuitry
- Protect or Disconnect Circuitry
- AC Line Protection:
- Thermal Fusing
- Integrated Cord Management
- Uses Electrical AC Ground
- Plug Configuration: Direct Plug-in
- Initial Clamping Level: 200V Peak, 141 Rms
- Response Time: 1-5 Nanoseconds
- Protection Modes: L-N, L-G, N-G
- UL 1449 Rating: 330V
- Protect or Disconnect Circuitry:
- Safeguards equipment against all surges. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.
- Diagnostic lights for your safety:
- Features Protection OK, Ground OK, and Line Fault lights to keep you informed of AC outlet status at all times.
- Plugs directly into wall:
- Protects two AC lines by easily plugging into wall. Side mounted outlets allow furniture to be moved closer to wall.
- AC SPECIFICATIONS:
- Protect or Disconnect Circuitry
- Thermal Fusing
- Catastrophic Surge Circuit
- Initial Clamping Level: 141V RMS/200V Peak
- Clamping Level (TVSS Voltage): 330V
Power Description
- Current:
- 15 A Line Current/52 kA Surge Current
- 15 A Line Current/52 kA Surge Current
- Surge Energy Rating:
- 1350 J
- 1350 J
- Input Voltage:
- 120 V AC
- 120 V AC
- Power Handling:
- 1.80 kVA
- 1.80 kVA
- Output Voltage:
- 120 V AC
- 120 V AC
- Filtering:
- EMI/RFI Noise Filtration: 50dB (99.7%)
- EMI/RFI Noise Filtration 50dB (99.7%)
- Frequency:
- 50 Hz
- 60 Hz
- 50 Hz or 60 Hz
Warranty
- Limited Warranty:
- Lifetime
- Lifetime
Controls/Indicators
- Status Indicators: 4 x Diagnostic LED
