Additional Information
| Connectivity | Cordless |
|---|---|
| Manufacturer AIDC | Metrologic |
| Model Name | MS9535 Voyager BT |
| Scanner Capability | 1D |
| Scanner Type | Laser |
Metrologic MS9535 Voyager BT Specs
Technical Information
- Barcode Dimension: 1D
- Scan Pattern: Single Line
- Scan Rate: 72 scan/s
- Connectivity Technology: Wireless
- Scanning Distance: 33 ft
- Light Source: Laser
- Barcode Symbology Supported:
- All Standard Symbologies
- RSS
- All Standard Symbologies
- RSS
- Maximum Scan Resolution: 5 mil
- Depth of Field:
- 0 mil - 2"@5.20 mil
- 0 mil - 5"@7.50 mil
- 0 mil - 7"@10.40 mil
- 0 mil - 8"@13 mil
- 1" - 10"@21 mil
General Information
- Product Type: Handheld Barcode Scanner
- Brand Name: Honeywell
- Manufacturer: Honeywell International, Inc
- Product Model: MS9535
- Product Name: VoyagerBT MS9535 Barcode Reader
- Product Line: VoyagerBT
Physical Characteristics
- Height: 7.8"
- Width: 3.1"
- Depth: 1.6"
- Color: Gray
- Weight (Approximate): 7.02 oz
Interfaces/Ports
- Host Interface: Keyboard Wedge
Other
- Package Contents:
- VoyagerBT MS9535 Barcode Reader
- 110V Power Supply
- Footprint Stand
- Straight Cable
- Cradle
- Manuals
- VoyagerBT MS9535 Barcode Reader
- 110V Power Supply
- Footprint Stand
- Straight Cable
- Cradle
- Manuals
- Certifications & Standards:
- Laser Class:
- Class 1 In accordance with IEC 60825-1:1993+A1:1997+A2:2001
- Class 1 In accordance with EN 60825-1:1994+A11:1996+A2:2001
- EMC:
- FCC
- ICES-003
- EN55022 Class B
- Platform Supported: PC
- Additional Information:
- Roll, Pitch, Yaw: 42°, 68°, 52°
- Profile Support: Serial Port Profile (SPP)
- Bluetooth Version: v1.1 compliant
- Termination: Base 10 pin modular RJ45
- Cable: Base 7 ft straight
- Input Voltage: Base
- DC Transformers: Scanner: none; Base: Class 2; 5.2 VDC @ 2 A
- Current Charging: 2 A
- Recharge Time: 2.5 hours
- Battery Capacity: 12,000 scans (max)
- Radio Range: 33 ft
- Frequency: 2.4 - 2.48 GHz (frequency hopping)
- System Interfaces:
- PC Keyboard Wedge
- RS232
- Light Pen Emulation
- Stand Alone Keyboard
- USB (low speed and full speed)
Network & Communication
- Bluetooth: Yes
Warranty
- Limited Warranty: 2 Year
Power Description
- Input Voltage: 110 V AC
