Motorola Symbol DS4308 Presentation Barcode Scanner

Performance Characteristics

Technology
Imager

Skew (Yaw)¹
± 60° or greater

Roll (Tilt) ²
0 - 360°

Pitch³
± 65° or greater

Print contrast
20% minimum reflective difference

Interfaces supported
Keyboard wedge, RS-232, USB, SSI, RS485 (IBM46xx)

Decode capability
See data sheet for full list of supported symbologies, 1-D/2-D

Physical Characteristics

Voltage and current⁴
5 VDC ± 10% @ 360 mA (RMS typical)

Weight
10.6 oz. / 300 g

Handheld
Yes

Dimensions
8.15 in. H x 5.18 in. L x 3.74 in. W
20.7 cm H x 13.15 cm L x 9.5 cm W

Corded
Yes

Regulatory Specifications

Environmental
Compliant with RoHS directive 2011/65/EU

Electrical Safety
EN 60950-1, CSA C22.2 No. 60950-1 2nd ed., UL60950-1 2nd ed, IEC60950-1 2nd ed

User Environment

Ambient lighting tolerance
Immune to normal indoor lighting up to 1600 Lux; immune to sunlight up to 86, 000 Lux

Storage temperature
-40° F to 158° F/-40° C to 70° C

Operating temperature
32° F to 122° F/0° C to 50° C

Humidity
5% to 95%, non-condensing

Drop specifications
Withstands multiple 5 ft./1.5 m drops to concrete
