Additional Information
| Manufacturer | PowerDsine |
|---|---|
| Model Name | Power Ethernet Hub |
Technical Information
- Compatibility:
- Wi-Max Access Points
- Gig IP Phones
- IP Cameras
- Input Voltage:
- 110 V AC
- 220 V AC
- Output Power: 15.40 W Per Port
- Output Voltage: 48 V DC
General Information
- Product Type: PoE Injector Hub
- Product Series: 3000
- Brand Name: PowerDsine
- Manufacturer: Microsemi Corporation
- Product Model: 3001
- Product Name: 3001 Power Over Ethernet Midspan
Physical Characteristics
- Height: 1.2"
- Width: 2.4"
- Depth: 5.7"
- Weight (Approximate): 1 lb
Interfaces/Ports
- Input Ports: 1 x RJ-45 10/100Base-TX
- Output Ports: 1 x RJ-45 10/100Base-TX
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority:
- RoHS
- WEEE
- Certifications & Standards:
- CE
- IEEE 802.3af compliant
- FCC Part 15, Class B with FTP cabling
- EN 55022 Class B (Conductive
- Emissions on Telecommunications Port)
- EN 55024 (Immunity)
- VCCI
- UL/cUL Per EN 60950
- GS Mark Per EN 60950
- CE
- IEEE 802.3af compliant
- FCC Part 15, Class B with FTP cabling
- EN 55022 Class B (Conductive
- Emissions on Telecommunications Port)
- EN 55024 (Immunity)
- VCCI
- UL/cUL Per EN 60950
- GS Mark Per EN 60950
- Compatibility:
- Wi-Max Access Points
- Gig IP Phones
- IP Cameras
- Additional Information:
- Indicators:
- System Indicator: AC Power (Green)
- User Indicator: Channel Power (Green)
Power Description
- Input Voltage Range: 90 V AC to 264 V AC
- Frequency: 47 Hz to 63 Hz
- Input Current:
- 500 mA @ 110 V AC
- 500 mA @ 220 V AC
- Input Voltage:
- 110 V AC
- 220 V AC
- Output Power: 15.40 W Per Port
- Output Voltage: 48 V DC
Environmental Conditions
- Altitude: -1000 ft to 10000 ft Operating
- Humidity: 93% Maximum Non-condensing Storage
- Temperature:
- 32°F (0°C) to 104°F (40°C) Operating
- -4°F (-20°C) to 158°F (70°C) Storage
Warranty
- Limited Warranty: 1 Year
