Powerware PW6S6K-LPD Products
Part #: PW6S6K-LPD | SKU: POW235255

Products and parts from Powerware.

Powerware PW6S6K-LPD Products

Part Details: PW9170 6KVA UPS Standard BDL 6 SLOT LC RECPS.

Need a different version of the Powerware Parts Accessory? View all 252 configurations

MSRP: $10,264.00 Price: $6,550.31

Additional Information

Manufacturer	Powerware
Model Name	Parts

Technical Information

Receptacles:
- 2 x NEMA L14-30R
- 2 x NEMA L6-30R
- 12 x NEMA 5-20R
Plug/Connector Type: NEMA 14-50P

General Information

Product Type: Online UPS
Brand Name: Eaton
Manufacturer: Eaton Corporation
Product Name: 9170+ Rackmount UPS 6 to 9 kVA UPS

Physical Characteristics

Form Factor: Rack-mountable

Interfaces/Ports

Modular Slots: 2 x Communications Slot

Management

Network Management: Optional
Battery Management: Advanced Battery Management
Alarm:
- Low Battery
- High Battery
- Low AC Output
- High AC Output
- High AC Input
- Output Overload
- Overload Shutdown
- High Heatsink Temperature
- Emergency Power Off
- Module Failure
- Excessive Transfer
- Precharge Failure
- Incompatible Module
- Fan Failure
- Low Runtime
- Check Memory
- Check Battery Open Cell
- Check Battery Weak Battery
- Low Redundancy Insufficient Battery
- Low Redundancy Insufficient Module
- Check Battery
- Phase Error
Bypass Switch: Automatic
Emergency Power OFF: Yes

Power Description

Input Voltage Range:
- 120 V AC
- 208 V AC
- 240 V AC
Load Capacity: 6 kVA/4.20 kW
Input Voltage:
- 110 V AC
- 220 V AC
Output Voltage:
- 120 V AC
- 208 V AC
- 240 V AC
Frequency:
- 50 Hz Input
- 60 Hz Input
Waveform Type: Sine Wave

Environmental Conditions

Altitude:
- 10000 ft Operating
- 40000 ft Non-operating
Cooling Type: Internal Fans
Humidity: 50 to 90% Non-condensing Relative Humidity
Temperature:
- 32°F (0°C) to 104°F (40°C) Operating
- -4°F (-20°C) to 104°F (40°C) Storage
Sound Emission: 50 dB(A)

Other

Certifications & Standards:
- UL
- CUL
- FCC class A
- IEEE/ANSI C62.41
Additional Information:
- Eliminates single point-of-failure with N+X power and logic redundancy
- Grows with changing IT environments by incorporating scalable design of 3 kVA power modules and batteries

Battery Information

Batteries: Maintenance-free Sealed Lead Acid Hot-swappable
Backup/Run Time:
- 0.13 Hour 4.20 kW Full Load
- 0.40 Hour 2.10 kW Half Load
Battery Recharge Time: <4 Hour Standard

Scalability

Modules:
- 2 x Power Module
- 4 x Battery Module
Power Range: 6 kVA to 9 kVA /

Controls/Indicators

Status Indicators: Battery Test Failed
Control Panel: LCD Status Screen

Warranty

Limited Warranty: 2 Year
