Powerware ZP21415000XX000 UPS
Part #: ZP21415000XX000 | SKU: POW211473

If the power goes out, will your Avaya telecommunications equipment remain up and running? The answer is a resounding, Yes! if you have an Avaya-labled UPS protecting it. Designed with a robust, online design and extended battery runtimes, the Avaya UPS completely isolates connected equipment from power disturbances so you don't have to worry about downtime. To make sure the UPS is fully integrated into your application, we have a full line of software and connectivity devices. Avaya UPS models range from 300 VA to 18kVA and most can be mounted in a 2-or 4-post rack enclosure.

Powerware ZP21415000XX000 UPS

Part Details: Eaton Preassembled BladeUPS - Bottom Entry 48 kW, 208V w/(1) Power Xpert SNMP/ModBus - Tower - 5 Minute Stand-by - 220 V AC Input - 208 V AC, 120 V AC, 228 V AC Output - Hard Wire 4-wire

Need a different version of the Powerware UPS Accessory? View all 291 configurations

MSRP: $64,600.00 Price: $52,553.19

Additional Information

Manufacturer	Powerware
Model Name	UPS

General Information

Product Type: Dual Conversion Online UPS
Brand Name: Eaton
Manufacturer: Eaton Corporation
Product Name: Preassembled BladeUPS - Bottom Entry 48 kW, 208V w/(1) Power Xpert SNMP/ModBus
Product Line: BladeUPS

Technical Information

Receptacles: Hard Wire 4-wire 3PH + G
Plug/Connector Type: Hardwired
Interfaces/Ports: 4 x RS-232 Serial

Physical Characteristics

Height: 81"
Width: 24"
Depth: 42"
Form Factor: Tower
Weight (Approximate): 1638.03 lb

Interfaces/Ports

Modular Slots:
- 2 x X-Slot
- 3 x Communications Slot
Interfaces/Ports: 4 x RS-232 Serial

Other

Package Contents:
- Preassembled BladeUPS - Bottom Entry 48 kW, 208V w/(1) Power Xpert SNMP/ModBus
- 1 x S-Series Rack on a Heavy-duty Shipping Pallet with Unloading Ramp BladeUPS Parallel bar and Wireway
- 4 x BladeUPS Modules
- Intelligent Power Software CD
- BladeUPS Installation and User Manual
- Rack Hardware Kit
- Front and Rear Rack Aesthetic Plates
- 1 x WEB/SNMP Card
- Comm Card Quick Start Guide
- Serial Configuration Cable USB
- Preassembled BladeUPS - Bottom Entry 48 kW, 208V w/(1) Power Xpert SNMP/ModBus
- 1 x S-Series Rack on a Heavy-duty Shipping Pallet with Unloading Ramp BladeUPS Parallel bar and Wireway
- 4 x BladeUPS Modules
- Intelligent Power Software CD
- BladeUPS Installation and User Manual
- Rack Hardware Kit
- Front and Rear Rack Aesthetic Plates
- 1 x WEB/SNMP Card
- Comm Card Quick Start Guide
- Serial Configuration Cable USB
Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS
Software Included: Eaton Intelligent Power Software

Power Description

Input Voltage Range:
- 180 V AC to 265 V AC
- 208 V AC Nominal
Load Capacity: 48 kW
Input Voltage: 220 V AC
Output Voltage:
- 208 V AC Nominal
- 120 V AC Nominal
- 180 V AC to 228 V AC
Frequency: 50 Hz Input

Battery Information

Batteries: 160 x Sealed, Maintenance-free Valve-regulated Lead Acid (VRLA) User Replaceable Hot-swappable
Backup/Run Time:
- 0.08 Hour 48 kW Full Load
- 0.22 Hour 24 kW Half Load

Management

Network Management: SNMP Manageable Included
Bypass Switch: Automatic
Emergency Power OFF: Yes

Scalability

Modules: 4 x Power Module

Warranty

Limited Warranty: 1 Year

Extended Details
