SATO 99-20002-604 Barcode Label Printer
Part #: 99-20002-604 | SKU: SAT214411

The Argox X-2300ZE 4" thermal transfer printers have an all-metal housing for heavy-duty printing. These printers can print up to 6 ips, and the adjustable dual-sensor system accommodates a variety of media. Changing settings, managing print jobs, and recovering from errors is simple using the LCD display and operation panel.

SATO 99-20002-604 Barcode Label Printer

Part Details: Competitive Emulation Z

Need a different version of the SATO Argox X-2300ZE Barcode Label Printer? View all 1 configurations

Additional Information

Interface Options	Ethernet, Parallel, Serial (RS-232), USB
Labels Per Day	2,500 - 7,500
Manufacturer	SATO
Max Roll Outer Diameter	8
Model Name	Argox X-2300ZE
Print Resolution	203 dpi
Print Speed	6 ips
Printer Type	Industrial
Printing Technology	Thermal Transfer
Ribbon Core Size	1 inch

SATO Argox X-2300ZE Specs (pdf)

Technical Information

Maximum Mono Print Speed: 6 in/s
Maximum Print Resolution: 203 dpi
Print Color: Monochrome
Maximum Print Width: 4.40"
Recommended Use: Label Print
Features: Real Time Clock
Barcode Symbology Supported:
- Code 39
- Code 93
- Interleaved 2 of 5
- EAN-8
- EAN-13
- UPC-A
- UPC-E
- POSTNET
- Codabar
- Code 128-A
- Code 128-B
- Code 128-C
- UCC/EAN 128
- Plessey
- Industrial 2 of 5
- Standard 2 of 5
- LOGMARS
- MSI
- Code 11
- GS1 DataBar
- Data Matrix
- Maxi Code
- PDF-417
- QR Code

General Information

Product Type: Direct Thermal/Thermal Transfer Printer
Product Series: X
Brand Name: Sato
Manufacturer: Sato Corporation
Product Model: X-2300ZE
Product Name: Argox X-2300ZE Desktop Label Printer

Physical Characteristics

Height: 10.4"
Width: 9.8"
Depth: 16.5"
Form Factor: Desktop
Weight (Approximate): 24.25 lb

Interfaces/Ports

USB: Yes
Serial Port: Yes

Media Types & Handling

Maximum Label Width: 4.33"
Media Type:
- Gap
- Black Mark
- Fanfold
- Roll Paper
Media Thickness: 10 mil
Media Sensor: Transmissive Media Sensor
Label Core Size: 3"
Ribbon Core Size: 1"
Maximum Roll Diameter: 8"

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS
Platform Supported: PC
Certifications & Standards:
- CE
- FCC
- UL
- CCC
- CUL

Power Description

Input Voltage:
- 110 V AC
- 220 V AC
Power Source: AC Supply

Network & Communication

Ethernet: Yes
Ethernet Technology: Ethernet

Memory

Standard Memory: 16 MB
Flash Memory: 8 MB

Display & Graphics

Display Screen Type: LCD

Fonts & Emulation

Language Emulation: PPLZ

Extended Details

Recommended Accessories for Model: SATO 99-20002-604 Barcode Label Printer

SATO 59-20012-001 Accessory
Part #: 59-20012-001 | SKU: SAT216016

HEAVY DUTY ROTARY CUTTER X2000V/X2300ZE FACTORY INSTALL

MSRP: $592.81 Price: $444.61
SATO 59-20001-011 Accessory
Part #: 59-20001-011 | SKU: SAT216012

ROTARY CUTTER X2000V/X2300ZE FACTORY INSTALLED

MSRP: $401.39 Price: $301.04
SATO 59-20005-002 Accessory
Part #: 59-20005-002 | SKU: SAT216014

Internal Label Rewind Option X2000V/X2300Ze Factory Install

MSRP: $188.89 Price: $141.67
