SATO XL400e Thermal Barcode Label Printer

The SATO XL400e has been discontinued. No direct replacement is available.
Please contact us for a suitable substitute.

Labels, Tags, Tickets and More: The XL400e can Handle it All!

The XL400e, which prints, cuts and stacks, is highly valued in the textile tag and ticketing industries. The movable sensor allows for an endless choice of media. The intelligent printhead regulates the printing temperature, thereby optimizing the print quality. A state-of-the-art RISC processor is at the heart of the XL400e, ensuring a high-speed printing process. The use of the cutter, and stacker enable you to select a solution suitable for your individual application.
  • Prints Labels, Tags, Tickets
  • Intelligent Printhead
  • Movable Sensor
  • Easy Connectivity
  • Print, Cut and Stack Solution
  • State-of-the-art Throughput
  • Windows Compatible
XL400e Options
SATO XL400e (WXL402041)
XL400e, Thermal transfer, 203 dpi, 8 ips, RS-232 Serial and Ethernet interfaces.
Specs: 8 ips - Direct thermal (DT), Thermal transfer (TT) - 3.94" Maximum Print width - 203 dpi - 1 x Serial, 1 x Ethernet
Recommended Accessories
SATO (PR7770100)
Label Sensor Assembly (for the CL412, CL408E and CL412E)
In Stock: Ships Today
$152.30
+ Add to Quote
SATO (WWCL45060)
M-8400RVe IEEE1284 Parallel Interface Card
In Stock: Ships Today
$103.13
Why don't we show the price?

SATO (PR1730900)
Ribbon boss for CL408E / CL412E series printers
In Stock: Ships Today
$22.90
+ Add to Quote
SATO (PL1770200)
Motor pulley for Cl408E, Cl408, Cl412E, Cl412 series printers
In Stock: Ships Today
$25.10
+ Add to Quote
SATO (WXL405101)
Stacker
Ships in 3-5 Days
$599.00
+ Add to Quote
Protect Your Product
SATO Service Contract - 1 year (OSBD-NEW-12)
Service Contract - 1 year, Minimize downtime and extend the life of your equipment with an On-Site Same-Day Service Plan for new printers. When trouble occurs, a technician will arrive on-site with repair parts in-hand.
Ships in 3-5 Days
$177.00
+ Add to Quote
SATO Service Contract - 2 year (OSBD-NEW-24)
Service Contract - 2 year, Minimize downtime and extend the life of your equipment with an On-Site Same-Day Service Plan for new printers. When trouble occurs, a technician will arrive on-site with repair parts in-hand.
Ships in 3-5 Days
$649.00
+ Add to Quote
SATO Service Contract - 3 year (OSBD-NEW-36)
Service Contract - 3 year, Minimize downtime and extend the life of your equipment with an On-Site Same-Day Service Plan for new printers. When trouble occurs, a technician will arrive on-site with repair parts in-hand.
Ships in 3-5 Days
$1,043.00
+ Add to Quote
SATO Service Contract - 1 year (OSMC-NEW-12)
Service Contract - 1 year, Minimize downtime and extend the life of your equipment with an On-Site Service Plan for new printers. When trouble occurs, a technician will arrive on-site in 48 hours with repair parts in-hand.
Ships in 3-5 Days
$115.00
+ Add to Quote
SATO Service Contract - 2 year (OSMC-NEW-24)
Service Contract - 2 year, Minimize downtime and extend the life of your equipment with an On-Site Service Plan for new printers. When trouble occurs, a technician will arrive on-site in 48 hours with repair parts in-hand.
Ships in 3-5 Days
$424.00
+ Add to Quote
Recommended Labels
SATO Thermal Labels (57TG02075)
Thermal Labels, 1.5" x 2.75" Direct thermal 7pt. paper tag. 3200 tags/roll, 2 roll case.
In Stock: Ships Today
$110.20
+ Add to Quote
SATO Thermal Labels (57TG02030)
Thermal Labels, 2.75" x 1.25" Direct thermal 7pt. paper tag. 7000 tags/roll, 2 roll case.
Ships in 3-5 Days
$87.40
+ Add to Quote
Recommended Ribbons
Recommended Printheads

SATO XL400e Details

XL400e - Tag and Label Printer

SATO's XL400e printer includes a heavy-duty print mechanism and cutter assembly. Its industrial chassis and 32-Bit RISC high performance processor tackles even the most demanding print jobs with ease.

Designed for the following applications:

  • Apparel Labeling
  • Hang Tags
  • Lumber Tags
  • Retail Tags
  • And Others

XL400e Enhancements:

  • User Adjustments
  • Printhead Replacement
  • Long Life
  • Diagnostics
  • High-Speed Processor
  • Plug-In Interfaces
  • Cutter Mechanism

XL400e

 XL410e

Printing Method

Thermal Transfer/Direct Thermal

Print Resolution

203 dpi (8 dots/mm)

305 dpi (12 dots/mm)

Print Speed

Up to 8 ips (200mm/sec)

Up to 6 ips (150mm/sec)

Max. Print Width

3.94" (100mm)

Max. Print Length

11.8" (300mm)

 9.4" (240mm)

Media Size

Min. 1.26" (32mm) W x 0.75" (19mm) L for Labels
Min. 1.26" (32mm) W x 0.98" (25mm) L for Tags
Max. 4.13" (105mm) W x 9.45 (240 mm) L

Max. Ribbon Size

Max. Length: 1476' (450m) - CSI

Dimensions

19.6" W x 11.8" D x 11.5" H
(302 mm W x 552 mm D x 294 mm H)

Weight

30.8 lbs. (14 kg)



Memory:
2 MB Std. Memory
2.95 MB Receive Buffer (max.)

Processor:
32-BIT RISC

Interface:

  • Standard Interfaces:
    • Serial - RS232C (up to 57.6k bps)
  • Optional Plug-In Interfaces:
    • Parallel - IEEE1284 (ECP)
    • Ethernet - 10/100BaseT
    • Wireless
    • USB

    Media:
    Roll or fan-fold labels or tags
    Max. 0.012" (0.31mm) Caliper
    Core Size: 4" I.D. 3" optional with adapter purchase
    Max. 9.84" (250 mm) Roll O.D.
    Wind Face-In or Face-Out – Print marking side wound face-in is recommended

    Media Detection:
    Eye-Mark; Gap; Center/Side Hole; Edge (R-Corner)

    Barcode Symbologies:
    Linear: UPC-A/E, EAN-8/13, Code 39/93/128, Bookland, Industrial 2/5, Interleaved 2/5, Matrix 2/5, Postnet, UCC/EAN 128, Codabar
    2-Dimensional: PDF417, Maxicode, Data Matrix, QR Code, Vericode

    Barcode:
    2:1, 5:2, 3:1 ratio; programmable height

    Human Readable Fonts:
    12 proportional, mono-spaced and outline fonts
    (Code table 858)
    8 POP fonts (Numeric only)
    Internal CG Triumvirate& CG Times fonts plus downloaded TrueType fonts

    Flexibility:
    360° rotation of barcodes and text, character expansion horizontally and vertically, sequential numbering, form overlay for high-speed editing of complex formats

    Options:
    Real Time Calendar/Clock, Stacker, Memory Expansion, Memory Card Interface Board
