Wasp WPL305 Barcode Label Printer
Part #: 633808402013 | SKU: WAS38762

The WPL305 from Wasp is the latest in a line of high-quality desktop printers. The WPL305 creates barcode labels at a rate of 5 inches per second at 203dpi. It is extremely user friendly, with easy installation and media loading.

Wasp WPL305 Barcode Label Printer

Part Details: WPL305, Desktop Barcode Label Printer with Cutter, WPL305, Thermal transfer, 5" outer diameter, 5 ips.
MSRP: $759.00 Price: $621.24

Additional Information

Filter Filter
Interface Options Parallel, Serial, USB
Label Core 1 inch
Manufacturer Wasp
Max Label Width 4.00
Max Roll Outer Diameter 5
Maximum Print Width 4.00
Model Name WPL305
Print Method Thermal Transfer
Print Resolution 203 dpi
Print Speed 5
Printer Mobility Not Mobile
Printer Type Desktop
Product Condition New

Technical Information

  • Maximum Mono Print Speed: 5 in/s
  • Maximum Print Resolution: 203 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 4.25"
  • Recommended Use: Label Print
  • Features: Cutter

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Brand Name: Wasp
  • Manufacturer: Wasp Barcode Technologies
  • Product Model: WPL305
  • Product Name: WPL305 Thermal Label Printer

Physical Characteristics

  • Height: 7.4"
  • Width: 8.4"

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes
  • Parallel Port: Yes

Other

  • Platform Supported: PC
  • Certifications & Standards:
    • CE
    • FCC
    • TUV
    • UL
  • Additional Information:
    • Compact Design
    • Easy Media Supplies loading
    • Font Rotations: 0, 90, 180, 270 degrees
    • Sensors:
    • Label Gap
    • Black Line
    • Head Open
    • Reflective (position adjustable)

Media Types & Handling

  • Maximum Label Width: 4.40"
  • Maximum Label Length: 39"
  • Media Type: Label
  • Media Size:
    • Custom Size - 4.40" x 984 ft
    • 4.40"
  • Media Sensor: Reflective Media Sensor
  • Label Core Size: 3"
  • Ribbon Core Size: 1"
  • Maximum Roll Diameter: 5"

Fonts & Emulation

  • Language Emulation:
    • WPL
    • EPL
    • ZPL

Memory

  • Standard Memory: 2 MB
  • Memory Technology: DRAM
  • Flash Memory: 1 MB

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC

Display & Graphics

  • Display Screen Type: LED

Cutter

  • Cutting Method: Automatic

Warranty

  • Limited Warranty: 1 Year
Extended Details

Recommended Accessories for Model: Wasp WPL305 Barcode Label Printer

  • Wasp Printer Accessories
    Part #: 633808402082 | SKU: WAS211859

    WPL305 Accessories, WPL305 Peeloff with Present Sensor
    MSRP: $49.00 Price: $42.16
    In Stock
  • Wasp Printer Accessories
    Part #: 633808402105 | SKU: WAS211857

    WPL305 Accessories, WPL305 Cutter OptIon Full Cut
    MSRP: $199.00 Price: $185.07
  • Wasp Printer Accessories
    Part #: 633808402068 | SKU: WAS147744

    Standalone Keyboard, KDU200 Standalone Keyboard acts as a portable terminal input device for standalone printing applications. No external power supply is needed.
    MSRP: $199.00 Price: $185.07
  • Wasp Printhead Kit
    Part #: 633808402167 | SKU: WAS147745

    Printhead Kit For Printer Model WPL205 & WPL305, Print Resolution 203 dpi
    MSRP: $199.00 Price: $194.64
    In Stock
  • Wasp WPL205 Label Rewinder
    Part #: 633808402099 | SKU: WAS147743

    WPL205 Accessories, WPL205/305 External Media Loader for 8"outer diameter Labels
    MSRP: $49.00 Price: $42.16

Recommended Labels for Model: Wasp WPL305 Barcode Label Printer

  • Wasp Direct Thermal Labels
    Part #: 633808402785 | SKU: WAS148075

    4" x 6" Direct thermal paper label. 4 roll case. labels/roll, 5" outer diameter.
    MSRP: $73.00 Price: $58.13
    In Stock
  • Wasp Thermal Transfer Labels
    Part #: 633808402518 | SKU: WAS148090

    2.25" x 0.75" Thermal transfer paper label. 4 roll case, 3000 labels/roll, 5" outer diameter.
    MSRP: $48.00 Price: $41.62
  • Wasp Direct Thermal Labels
    Part #: 633808402761 | SKU: WAS144561

    4" x 2" Direct thermal paper label, 4 roll case, 1250 labels/roll, 5" outer diameter.
    MSRP: $81.00 Price: $65.10
    In Stock
  • Wasp Direct Thermal Labels
    Part #: 633808402747 | SKU: WAS148021

    3.5" x 1" Direct thermal paper label. 4 roll case. 2300 labels/roll, 5" outer diameter.
    MSRP: $74.00 Price: $60.45
  • Wasp Thermal Transfer Labels
    Part #: 633808402556 | SKU: WAS148093

    4" x 1" Thermal transfer paper label. 4 roll case, 2300 labels/roll, 5" outer diameter.
    MSRP: $67.00 Price: $61.29
    In Stock

Recommended Ribbons for Model: Wasp WPL305 Barcode Label Printer

  • Wasp Barcode Ribbon
    Part #: 633808431235 | SKU: WAS38767

    Ribbons, WPL305/WPL608/WPL610 WXR 3.26" x 820' Resin Ribbon
    Price: $29.81
    In Stock
  • Wasp Barcode Ribbon
    Part #: 633808431228 | SKU: WAS38766

    Ribbons, WPL305/WPL608/WPL610 WXR 2.16" x 820' Resin Ribbon
    Price: $27.95
    In Stock
  • Wasp Barcode Ribbon
    Part #: 633808431143 | SKU: WAS38765

    Ribbons, WPL305/WPL608/WPL610 WWX 2.16" x 820' Wax Ribbon
    Price: $22.37
    In Stock
  • Wasp Barcode Ribbon
    Part #: 633808431181 | SKU: WAS23889

    Ribbons, WPL305/WPL608/WPL610 WPR 2.16" x 820' Wax-Resin Ribbon.
    Price: $23.30
    In Stock
  • Wasp Barcode Ribbon
    Part #: 633808431150 | SKU: WAS148108

    Ribbons, WPL305/WPL608/WPL610 WWX 3.26" x 820' Wax Ribbon.
    Price: $23.30

Recommended Warranties for Model: Wasp WPL305 Barcode Label Printer

  • Wasp Service Contract
    Part #: 633808600136 | SKU: WAS147742

    Service Contract - 2 year, Protect Extended Service Plan for WPL305 Printer, 48 HR-2 Year
    Price: $92.84
    In Stock
  • Wasp Service Contract
    Part #: 633808600488 | SKU: WAS211889

    WaspProtect WPL305 1 Year Service Renewal
    Price: $134.93
    In Stock
