Zebra MS-954-I000R Fixed Barcode Scanner Zebra MS-954-I000R Fixed Barcode Scanner Zebra MS-954-I000R Fixed Barcode Scanner Zebra MS-954-I000R Fixed Barcode Scanner

Zebra MS-954-I000R Fixed Barcode Scanner
Part #: MS-954-I000R | SKU: ZEB21548

The MS954 is a compact, durable, fixed-mount scanner that provides high performance linear scanning on all types of 1D bar codes, including poorly printed and low contrast symbols. The MS954 offers a configurable scan angle of 47 and 35 for OEM devices requiring a flexible, expanded working range. As one of the smallest, lightest and brightest fixed-mount scanners available today, the MS954 is ideal for accurate automated data collection in OEM device designs with space constraints, such as kiosks and ATMs, clinical diagnostic equipment, medical instruments, gaming devices and turnstiles/access control.

Zebra MS-954-I000R Fixed Barcode Scanner

Part Details: Fixed Mount Scanner - Symbol MS954 - RS-232 Serial - General Purpose - 1D Laser - Class 2 - Standard Laser SL - No USB -
Need a different version of the Symbol MS954 Fixed Barcode Scanner? View all 1 configurations
$241.34
See Price in Cart (Why?)
In Stock

Additional Information

Manufacturer AIDC Zebra
Model Name MS954
Scanner Capability 1D
Scanner Type Laser
Zebra MS954 Specs Zebra MS954 Specs (pdf)

Technical Information

  • Barcode Dimension: 1D
  • Scan Pattern: Linear
  • Scan Rate: 12 scan/s
  • Connectivity Technology: Cable
  • Light Source: Laser
  • Barcode Symbology Supported:
    • UPC/EAN
    • Code 128
    • UCC/EAN 128
    • Code 39
    • Code 93
    • Discrete 2 of 5
    • Codabar
    • MSI
    • RSS
    • 1-D Composite Codes
    • UPC/EAN
    • Code 128
    • UCC/EAN 128
    • Code 39
    • Code 93
    • Discrete 2 of 5
    • Codabar
    • MSI
    • RSS
    • 1-D Composite Codes
  • Depth of Field:
    • 0.70" - 7.30"@5 mil
    • 0.90" - 12.30"@7.50 mil
    • 0.90" - 22"@ - 100%UPC
    • 0 mil - 27.50"@20 mil
    • 0 mil - 28"@40 mil
    • 0 mil - 36"@55 mil

General Information

  • Product Type: Fixed Mount Barcode Scanner
  • Brand Name: Motorola
  • Manufacturer: Motorola, Inc
  • Product Model: MS954
  • Product Name: Symbol MiniScan 954 Barcode Reader
  • Product Line: MiniScan

Physical Characteristics

  • Height: 1"
  • Width: 1.9"
  • Depth: 2.3"
  • Weight (Approximate): 1.67 oz

Interfaces/Ports

  • Host Interface: Serial

Power Description

  • Input Voltage: 5 V DC

Warranty

  • Limited Warranty: 1 Year
Extended Details

Recommended Accessories for Model: Zebra MS-954-I000R Fixed Barcode Scanner

  • Zebra 23844-00-00R Power Device
    Part #: 23844-00-00R | SKU: ZEB26223

    US AC Line Cord - 7.5' Length - Compatible with power supplies (Part# KT-14000-148R), (Part# 50-14000-241R), and (Part# PWRS-14000-148R)
    MSRP: $17.94 Price: $15.76
    In Stock

  • Zebra CBL-58918-02 Cables, Connectors, and Adapters
    Part #: CBL-58918-02 | SKU: ZEB360721

    Cable, Assembly (6 Foot, FM Cable Assembly, RS-232, STR). Requires power supply (part# PWR-WUA5V4W0US)
    $33.82
    See Price in Cart (Why?)
    In Stock

  • Zebra PWR-WUA5V4W0US Power Device
    Part #: PWR-WUA5V4W0US | SKU: ZEB453605

    Power Device - Zebra - Level Vi AC/DC Power Supply Wall Adapter - With Captive DC Cable And US Adapter Clip AC Input - 100-240V - 0.2A DC Output - 5.2V - 1.1A - 5.7W
    $52.14
    See Price in Cart (Why?)
    In Stock

  • Zebra PWR-WUA5V4W0EU Power Device
    Part #: PWR-WUA5V4W0EU | SKU: ZEB599320

    Power Systems & Supplies - Zebra - Level VI AC/DC Power Supply (Wall Adapter - with Captive DC Cable and Eu - Uk Adapter Clip). AC Input: 100-240V - 0.2A. DC Output: 5.2V - 1.1A - 5.7W
    $41.38

  • Zebra 25-62186-03R Cables, Connectors, and Adapters
    Part #: 25-62186-03R | SKU: ZEB129627

    RS-232 Cable Assembly - 9 Pin Female Straight Host Connector - Converts TTL (5V) Signal at Scanner to True RS-232 (+/- 12V) Signal at Host - To Be Used with General Purpose Fixed Scanners
    $64.81
    See Price in Cart (Why?)
View All Options
