Additional Information
| Manufacturer | Zebra |
|---|---|
| Model Name | QLn320 |
| Print Resolution | 203 dpi |
Zebra QLn320 Specs
Zebra QLn320 Driver
Technical Information
- Maximum Mono Print Speed: 4 in/s
- Peel Facility: Yes
- Maximum Print Resolution: 203 dpi
- Print Color: Monochrome
- Maximum Print Width: 2.90"
- Recommended Use: Label Print
- Features:
- Belt Clip
- Tear Bar
- Mirror Printing
- Label Odometer
- Real Time Clock
- Vertical Printing
- Horizontal Printing
- Peel Facility
- Dust Resistant
- Water Resistant
- Hand Strap
- Shoulder Strap
- Barcode Symbology Supported:
- Code 39
- Code 93
- UCC/EAN 128
- Code 128
- Codabar
- Interleaved 2 of 5
- UPC-A
- UPC-E
- EAN-13
- EAN-8
- PDF-417
- Micro PDF-417
- Maxi Code
- QR Code
- RSS
- GS1 DataBar
- Aztec Code
- Data Matrix
- TLC 39
- FIM
- POSTNET
- Plessey
General Information
- Product Type: Direct Thermal Printer
- Product Series: QLn
- Brand Name: Zebra
- Manufacturer: Zebra Technologies Corporation
- Product Model: QLN320
- Product Name: QLn320 Mobile Printer
Physical Characteristics
- Height: 3.3"
- Width: 4.6"
- Depth: 6.8"
- Form Factor: Portable
- Weight (Approximate): 1.60 lb
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
- Platform Supported: PC
- Package Contents:
- QLn320 Mobile Printer
- Software & Drivers CD
- Battery
- QLn320 Mobile Printer
- Software & Drivers CD
- Battery
- Certifications & Standards:
- IP54
- FCC Part 15, Subpart B
- EN55022 Class-B
- EN60950
- EN55024
- VCCI class B
- EN55024
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
- CE
- UL
- TUV
- CSA
- IP43
- IP54
- Unicode
- UTF-16
Media Types & Handling
- Maximum Label Width: 3.10"
- Maximum Label Length: 32"
- Media Type:
- Linerless
- Black Mark
- Gap
- Roll Fed
- Direct Thermal Label
- Label
- Media Thickness: 6.50 mil
- Media Sensor:
- Transmissive Media Sensor
- Label Taken Sensor
- Reflective Media Sensor
- Label Core Size: 0.75"
- Maximum Roll Diameter: 2.60"
Fonts & Emulation
- Language Emulation:
- CPCL
- ZPL
- XML
Battery Information
- Battery Included: Yes
- Battery Rechargeable: Yes
- Battery Chemistry: Lithium Ion (Li-Ion)
Network & Communication
- Bluetooth: Yes
- Ethernet: Yes
- Ethernet Technology: Fast Ethernet
Memory
- Standard Memory: 128 MB
- Flash Memory: 256 MB
Power Description
- Input Voltage: 7.4 V DC
- Power Source: Battery
Warranty
- Limited Warranty: 1 Year
Display & Graphics
- Display Screen Type: LCD
